4A-C4L-10-NE-SS-C3
Check Valve - Inline - C
Parker Inline Check Valve - C Series
| Manufacturer |
Parker |
| Part Number |
4A-C4L-10-NE-SS-C3 |
| Availability |
Out of Stock
Call to order
|
| UOM |
EA |
| Description: |
Parker C Series Check Valves are designed for uni-directional flow control of fluids and gases in industries such as chemical processing, oil and gas production and transmission, pharmaceutical, pulp and paper, power and utilities.
|
Inlet port 1:
1/4" A-LOK compression
Outlet port 2:
1/4" A-LOK compression
Material - Seats:
Neoprene rubber
Cracking pressure:
10 psi (0.7 bar)
Material:
Stainless Steel
Pressure Range:
Low pressure
Configuration Type:
Inline
Connection Type:
Double ferrule compression
Operating Temperature:
-45 F to 250 F (-43 C to 121 C)
Cracking Pressure:
10 psi (0.7 bar)
Lubricant:
Perfluorinated polyether
Parker Division:
Instrumentation Products
Parker Group:
Instrumentation
Pressure Rating:
6,000 psig (414 bar) CWP
Special Cleaning:
Cleaning for oxygen service
Orifice size:
0.187 Inch (4.7mm)
Application:
In the key markets of chemical & refining, food, beverage & dairy, medical & dental, microelectronics, oil & gas, and power generation.
Safety Notice
WARNING: Products containing brass have a chemical known to the State of California to cause birth
defects or other reproductive harm. Do not use in connection with drinking water. Wash hands after handling.
