Back to Product: Wika 4348326 Hazardous Area Non-incendive Pressure Transmitter Model N-10 4-20MA 2-wire 1/4 NPT Male X 1/2 NPT Male With 6 FT Cable Stainless Steel
Click Image to Zoom
4348326 Wika 4348326 Hazardous Area Non-incendive Pressure Transmitter Model N-10 4-20MA 2-wire 1/4 NPT Male X 1/2 NPT Male With 6 FT Cable Stainless Steel4348326 Wika 4348326 Hazardous Area Non-incendive Pressure Transmitter Model N-10 4-20MA 2-wire 1/4 NPT Male X 1/2 NPT Male With 6 FT Cable Stainless Steel
*ACTUAL PRODUCT MAY DIFFER FROM IMAGE SHOWN. IT IS BUYERS RESPONSIBILITY TO VERIFY ACTUAL PRODUCT SPECIFICATION MEETS INTENDED REQUIREMENTS BY REVIEWING ITEM SPECIFICATIONS AND RELATED DOCUMENTATION LISTED BELOW.

4348326

Wika 4348326 Hazardous Area Non-incendive Pressure Transmitter Model N-10 4-20MA 2-wire 1/4 NPT Male X 1/2 NPT Male With 6 FT Cable Stainless Steel

Hazardous Area Non-incendive Pressure Transmitter

Manufacturer Wika
Part Number 4348326
Availability Out of Stock (0) Out of Stock - Lead Time Required
Out of Stock quantities: Call for availability.
UOM EA
Price: $508.18
Qty:
Description:
Wika Model N-10 pressure transmitters are specifically designed to meet the durability and performance requirements of gas compressor systems. These pressure transmitters feature an industry standard 4-20 mA 2 wire signal output, NEMA 4X (IP 67) weather protection and are extremely resistant to pressure spikes, vibration and moisture intrusion. NACE MR-01-75 compliance provides extra resistance against sulfide stress cracking when exposed to gases containing sulphur.
Email this page to a friend

Product Attributes


UOM:
EA
Process Connection:
1/4 NPT Male
Electrical Connection:
1/2 NPT Male w/ 6 ft cable
Range:
30 PSI
Transmitter Output:
4-20MA, 2-wire
Supply Voltage:
10-30 VDC
Material:
Stainless Steel
Country of Origin (COO):
Special request, please call for COO
Harmonized Tariff (HTS):
Special request, please call for HTS
Series:
N-10
Accuracy:
±0.5% of span
Wetted Parts:
Stainless Steel
Non-linearity:
±0.25% of span BFSL
Manufacturer:
Wika
Application:
Natural gas compressors, wellhead monitoring, pipeline pressure, and other general industrial applications.

Safety Notice

WARNING: Products containing brass have a chemical known to the State of California to cause birth defects or other reproductive harm. Do not use in connection with drinking water. Wash hands after handling.

Part Number Tags: 4348326

Product Resources
N-10 Model
N-10 Model
