Back to Product: Wika 52346587 Low Pressure Gauge Model 611.10 4 Inch Dial 30 VAC INWC 1/4 NPT Center Back Mount U-clamp Black Steel Case
Click Image to Zoom
52346587 Wika 52346587 Low Pressure Gauge Model 611.10 4 Inch Dial 30 VAC INWC 1/4 NPT Center Back Mount U-clamp Black Steel Case52346587 Wika 52346587 Low Pressure Gauge Model 611.10 4 Inch Dial 30 VAC INWC 1/4 NPT Center Back Mount U-clamp Black Steel Case
*ACTUAL PRODUCT MAY DIFFER FROM IMAGE SHOWN. IT IS BUYERS RESPONSIBILITY TO VERIFY ACTUAL PRODUCT SPECIFICATION MEETS INTENDED REQUIREMENTS BY REVIEWING ITEM SPECIFICATIONS AND RELATED DOCUMENTATION LISTED BELOW.

52346587

Wika 52346587 Low Pressure Gauge Model 611.10 4 Inch Dial 30 VAC INWC 1/4 NPT Center Back Mount U-clamp Black Steel Case

Low Pressure Gauge

Manufacturer Wika
Part Number 52346587
Availability Out of Stock Call to order
UOM EA
Call for availability
Description:
Wika Model 611.10 low pressure gauges are extremely sensitive and highly accurate. The capsule element pressure system is designed to measure pressure and vacuum of gaseous media from as low as 10” H2O to 275” H2O (10 psi). The finely polished nickel-silver pinion gear and shaft of the movement ensure repeatable accuracy.
Email this page to a friend

Product Attributes


UOM:
EA
Dial Size:
2-1/2
Connection Size:
1/4 NPT
Connection Location:
Center Back Mount U-clamp
Case Material:
Black Steel
Gauge Fill:
Dry
Gauge Pressure Range:
30 VAC INWC
Country of Origin (COO):
Special request, please call for COO
Harmonized Tariff (HTS):
Special request, please call for HTS
Series:
611.10
Accuracy:
±1.5% of span
Dial Material:
White aluminum
Window:
Snap-in acrylic
Window Ring:
None
Wetted Parts:
Copper Alloy Movement
Pointer Material:
Black aluminum
Manufacturer:
Wika
Application:
Low pressure pneumatic systems - fluid medium, gaseous or dry, which does not clog connection port or corrode copper alloy.
Specific Application:
Process industry: chemical/petrochemical, power stations, mining, on and offshore, environmental technology, mechanical engineering and plant construction.

Safety Notice

WARNING: Products containing brass have a chemical known to the State of California to cause birth defects or other reproductive harm. Do not use in connection with drinking water. Wash hands after handling.

Part Number Tags: 52346587

Product Resources
611.10 Series
611.10 Series
