Liquid Inlet Connection:
1/2" FNPT
Liquid Outlet Connection:
1/2" FNPT
Liquid Inlet Location:
Side
Isolation Chamber:
Included
Liquid Seal Material:
Thermoplastic polyester u-cup with EPDM o-rings
Country of Origin (COO):
Special request, please call for COO
Harmonized Tariff (HTS):
Special request, please call for HTS
Material:
Stainless Steel
Parker Group:
Instrumentation
Parker Division:
Autoclave Engineers
Maximum Outlet Pressure:
13,300 psi (917 bar)
Volume Displacement per Cycle:
7.8 in³ (127.8 cm³)
Maximum Operating Temperature:
0 F to 140 F (-18 C to 60 C)
Air Drive type:
Double acting, double piston
Air Piston Diameter:
10 Inch
Main Air Drive Supply Connection:
1" FNPT
Application:
In the key markets of oil and gas, chemical, industrial and research industries.
