Port Size:
1-1/2" NPT Female
Electrical Termination:
18 AWG, 24"-26" long Polymeric Leads
Recommended Filtration:
150 micron
Body Material:
316 Stainless Steel
Wetted Materials:
316 Stainless Steel, Teflon®, Viton, Ceramic
Country of Origin (COO):
Special request, please call for COO
Harmonized Tariff (HTS):
Special request, please call for HTS
Component Type:
Flow Switches & Sensors
Component Sub-Type:
Shuttle Type Flow Switches
Set Point Differential (Maximum):
15%
Sensor Type:
Shuttle Type
Minimum Pressure:
300 - 500 PSI
Maximum pressure:
400 PSI @ 70° F
Minimum Temperature:
-20° F
Materials of Construction:
Alloy
Maximum Temperature:
300° F
Manufacturer:
Gems Sensors
Markets:
General Industry, Marine, Medical, OHV & Specialty Vehicle, Oil & Gas, Process, Semiconductor
Safety/Certifications:
UL Recognized, UL Explosion Proof, CE, CSA, FM
Additional Specifications:
To view full product information see product resources section on this page
Specific Application:
Protect Bearings or Gears (oil separators, fuel systems, pumps, compressors, presses), Electronics or Machinery (heat exchangers, semiconductor manufacturing equipment, induction furnaces, radio transmitters), Process Systems (water filtration and reverse osmosis, chlorinators, de-icers, sterilizers, evaporators)
