Rating (GVW):
Class 7 and 26,001 to 33,000 lbs
Purge Chamber Capacity:
98 In.³ (1.6L)
Desiccant Weight:
1.1 lbs (0.5 kg)
Country of Origin (COO):
Special request, please call for COO
Harmonized Tariff (HTS):
Special request, please call for HTS
Width:
6.32 Inch (16.1 cm)
Configuration Type:
Compressed Air Dryer
Height:
11.0 Inch (28 cm)
Operating Temperature:
-22 F to 158 F (-30 C to 70 C)
Governor Differential Pressure:
14.5-18.8 psi (1.0-1.3 bar)
Governor Cut-Out Pressure:
100-129 psi (6.9-8.9 bar)
Pressure Governor and Check Valve:
Yes
Standard Flow Per Cycle:
9,459 In.³ (155L)
Air Reservoir Volume:
40 gal @ 14.5 psi / 31 gal @ 18.8 spi
Regenerate Time Required:
50 seconds
Application:
Compressed air and air suspension systems.
