Liquid Inlet Connection:
1/2" FNPT
Liquid Outlet Connection:
1/2" FNPT
Liquid Inlet Location:
Side
Liquid Seal Material:
UHMWPE u-cup with Viton o-rings
Country of Origin (COO):
Special request, please call for COO
Harmonized Tariff (HTS):
Special request, please call for HTS
Material:
Stainless Steel
Parker Group:
Instrumentation
Parker Division:
Autoclave Engineers
Maximum Outlet Pressure:
11,200 psi (772 bar)
Maximum Operating Temperature:
0 F to 140 F (-18 C to 60 C)
Air Drive type:
Single acting, double piston
Air Piston Diameter:
6 Inch
Main Air Drive Supply Connection:
1/2" FNPT
Volume Displacement per Cycle:
1.50 in³ (24.64 cm³)
Application:
In the key markets of oil and gas, chemical, industrial and research industries.
